2D/3D CAD drawings

CAD drawings of Vuototecnica products just a click away!

Disegni CAD dei prodotti Vuototecnica

Product code:

Are you a designer and do you have to find the card of a particular vacuum cup or all the multistage generator models?
Do you need to design grippers for robots and in-line gripping systems on CAD?
Do you wish to download native format 3D drawings, in the format most suitable for you?
Do you work in a purchasing office and want to have the product coding details available?

For these and other needs, Vuototecnica facilitates your work, making an innovative tool for searching and downloading technical drawings available for its products.

Simply enter the product code or product family to find the technical drawing you need, in the most appropriate formats for each CAD. The system allows the search of the product code both with and without spaces, does not distinguish between upper and lower case letters and allows the search also by entering only the first 3 characters of the product code.

The tool is multilingual and accessible 24/7.

CAD design has never been easier! Seeing is believing.
